32-Port 40G Data Center Switch
DQS-5000-32S
- Product Status: Live
- 32 x 40G QSFP+ ports
- Wire-speed, ultra-low latency switching
- Supports Open Network Install Environment (ONIE) for zero-touch installation of network OS
- SDN-enabled with OpenFlow 1.3 support
- Dual AC/DC hot-swappable power supply modules for 1+1 redundancy and load sharing
- Modular n+1 hot-swappable fan design
Specs
|
Acoustic
|
Max: 69.8 dB Min: 59.5 dB |
|---|---|
|
Console Port
|
1 x RJ-45 console port |
|
Memory
|
12 MB |
|
OOB Management Port
|
1 x 10/100/1000BASE-T RJ-45 port |
|
Dimensions
|
440 x 406 x 44 mm (17.32 x 16 x 1.73 inch) |
|
FAN
|
Fan x 4 |
|
Humidity
|
Operating: 5% to 95% RH, non-condensing |
|
Interfaces
|
1 x RJ-45 Management port 1 x RJ-45 port 1 x USB 2.0 port 32 x 40G QSFP+ ports |
|
MAC Address Table Size
|
288K |
|
Maximum Forwarding Rate
|
1,428 Mpps |
|
Maximum Heat Dissipation
|
1385.27 BTU/hr |
|
Maximum Power Consumption
|
406 W |
|
MTBF
|
85,937 hours |
|
Power Input
|
1+1 redundant power supply design Input: 100 to 240 V AC, 50/60 Hz |
|
Switching Capacity
|
2.56 Tbps |
|
Temperature
|
Operating: 0 to 45 ºC (32 to 113 ºF) |
|
Weight
|
9 kg (19.8 lbs) |
