12-Port Gigabit Smart Managed Industrial PoE Switch-Wide Temp-240W PoE Budget
DIS-200G-12PSW
- Product Status (Revision A1 v104): Live
- 8 x 10/100/1000BASE-T PoE ports
- 2 x 10/100/1000BASE-T ports
- 2 x SFP ports
- 1 x RJ-45 Console port
- Wide operating temperature: -40 to 75 °C (-40 to 167 °F)
- Robust industry-standard enclosure
- ERPS for quick failover recovery
- High EMC endurance
- Built-in 6 kV surge protection
Durable and Reliable Design
The DIS-200G Series switches are housed in a highly resistant IP30-rated metal casing to protect them from harsh environmental conditions. The high electromagnetic compatibility (EMC) protects the DIS-200G Series from unwanted effects when operating in environments with strong electromagnetic interference.
High Redundancy and Reliability
The DIS-200G Series supports ERPS quick failover recovery for ring topologies that ensures minimal downtime and avoids any loss of data in mission-critical deployment settings. Meanwhile, the dual power input allows for a redundant power supply to make sure the device continues to operate in the event of a primary power supply failure.
Surveillance Traffic Optimization
The DIS-200G Series supports the Auto-Surveillance VLAN (ASV) feature. This automatically detects surveillance devices and puts them into a dedicated surveillance VLAN, segmenting this type of traffic from the rest of the network.
Easy Troubleshooting
The DIS-200G Series features loopback detection and cable diagnostics to help network administrators find and solve network problems quickly and easily. Loopback detection is used to detect loops created by a specific port and automatically shuts down the affected port.
Industrial Switches
Our industrial-grade switches are certified to endure and perform even in the toughest of environments
Specification
|
Interfaces
|
2 x 1000Base-T 8 x 1000Base-T PoE 2 x 1000M SFP Auto MDI/MDIX |
|---|---|
|
Console Port
|
Supported
|
|
Switching Capacity
|
24 Gbps |
|
Maximum Forwarding Rate
|
17.856 Mpps |
|
Store & Forwarding Forwading
|
Yes |
|
Humidity
|
Operating: 0% - 95% RH Storage: 0% - 95% RH |
|
Weight
|
1.76kg (3.88lbs) |
|
Temperature
|
Operating -40 ~ 75℃ Storage -40 ~ 85℃ |
|
Operating Altitude
|
up to 2000M |
|
Max Power Consumption
|
260W (PoE on) 10.8W (PoE off) |
|
Standby Power Consumption
|
7.02W |
|
Maximum Heat Dissipation
|
887.16 BTU/hr 36.85 BTU/hr |
|
MTBF
|
156,452 hours |
|
Dimensions
|
210 x 171.2 x 53mm |
|
CPU Speed
|
416MHz |
|
DRAM Size
|
128 MB |
|
Flash Memory Size
|
32 MB |
|
Packet Buffer Size
|
4 Mbits |
|
Power Input
|
46-54Vdc redundant dual inputs throught ternimal block/54Vdc through 4-pin power din |
|
Comply with RoHS 6
|
Yes |
|
Energy Efficiency Ethernet (EEE)
|
Yes |
|
Power Saving
|
By LED Shut-Off By Link Status By Port Shut-Off By System Hibernation |
|
PoE Power Budget
|
240 W max |
|
MAC Address Table Size
|
8000 |
|
Control
|
802.3x Flow |
|
Head-of-line (HOL) Blocking Prevention
|
Yes |
|
Spanning Tree Protocol (STP)
|
IEEE 802.1D STP IEEE 802.1s MSTP IEEE 802.1w RSTP |
|
Ethernet Ring Protection Switching(ERPS)
|
G.8032 |
|
Aggregation
|
6 x Link Aggregation Group Per Device 8 x Max Port Per Link Aggregation Group 802.1AX Link 802.3ad Link |
|
Jumbo Frame
|
9600 bytes |
|
MLD
|
Snooping Snooping Fast Leave Snooping Groups |
|
VLAN
|
802.1Q Asymmetric VLAN Auto Surveillance VLAN GVRP Port-based VLAN Surveillance VLAN VLAN Groups Voice VLAN |
|
QoS
|
4 x Queue Class of Service (CoS) Port-based Bandwidth Control Queue Handling Strict Priority Queue (SPQ) Weighted Round Robin _WRR |
|
Security
|
Broadcast/Multicast/Unicast Storm Control D-Link Safeguard Engine DoS Attack Prevention Port Security Traffic Segmentation |
|
OAM
|
Cable Diagnostics Optical Transceiver Digital Diagnostic Monitoring (DDM) |
|
AAA
|
RADIUS Web_based Access Control _WAC |
|
Management
|
Command Line Interface (CLI) D-Link Discover Protocol (DDP) DHCP Client Dual Images LLDP RMONv1 Simple Network Time Protocol (SNTP) SNMP SNMP Trap System Log Telnet Server TFTP Client Web_based GUI |
|
Dual Configurations
|
Yes |
|
Ping
|
Yes |
|
D-Link Network Assistant
|
Yes |
|
Protection
|
Surge/Lightning Protection (AC Power Inet) 2KV Surge/Lightning Protection (All Ethernet Ports) 6KV |
|
Discharge
|
Air Discharge 8KV Contact Discharge 6KV |
|
Features
|
Loopback Detection (LBD) Port Mirroring |
|
IGMP Snooping
|
IGMP Snooping Fast Leave 256 IGMP snooping groups (shared with MLD snooping) |
|
Actual performances may vary due to settings, cabling, temperature, network configuration, interface, device compatibility, environmental and on-site conditions, and other similar factors. References to power capability, signal or processing speed, signal range or distance, data encryption, storage capacity, display properties, or other performance metrics are based on optimal conditions derived from industry standards and provided for informational purposes only.Specifications may be subject to change without prior notice. |
|
