D-Link's innovative Safeguard Engine protects switches against traffic flooding and virus attacks. 802.11X port-based authentication allows the network to be authenticated through external RADIUS servers. In addition, the Access Control List (ACL) feature enhances network security and helps to protect the internal IT network.
|
Interfaces
|
8 x 10/100/1000BASE-T PoE ports 2 x SFP ports |
|---|---|
|
Switch Capacity
|
20 Gbps |
|
Max. Packet Forwarding Rate
|
14.88 Mpps |
|
Dimensions
|
280 x 126 x 44 mm |
|
Weight
|
0.95 kg |
|
Temperature
|
Operating: -5 to 50° C (23 to 122° F) Storage: -20 - 70 ˚C |
|
Operating Altitude
|
1500 m |
|
Max Power Consumption
|
89.1 W/100 V, 80.6 W/240 V(PoE on) 7.6 W/100 V, 7.5 W/240 V(PoE off) |
|
Standby Power Consumption
|
2.5 W/100V 2.5 W/240V |
|
Humidity
|
Operating: 0% - 95% RH Storage: 0% - 95% RH |
|
Maximum Heat Dissipation
|
279.59 BTU/hr (100V) 275.04 BTU/hr (240V) |
|
MTBF
|
729,258 hours |
|
Power Input
|
100 to 240 V AC |
|
CPU Speed
|
500MHz |
|
DRAM Size
|
DDR3 128MB |
|
Flash Memory Size
|
32 MB |
|
Packet Buffer Size
|
4.1Mbits |
|
FAN
|
Fanless |
|
Acoustic
|
0 dB |
|
PoE Budget
|
65 W |
|
實際效能可能因設定、線纜、溫度、網路配置、介面、設備相容性、環境和現場條件以及其他類似因素而有所不同。有關功率、訊號或處理速度、訊號範圍或距離、資料加密、儲存容量、顯示特性或其他效能指標的說明均基於業界標準得出的最佳條件，僅供參考。規格如有變更，恕不另行通知。 |
|
