8-Port Gigabit Easy Smart Switch

DGS-1100-08V2

  • Product Status (Ax v2.11WW): Live
  • 8 Ports GE Ethernet for downlink
  • Fanless design
  • Broadcast/Multicast/Unicast Storm Control
  • Static Port Trunking
  • 802.1D STP/ 802.1w RSTP
  • IGMP Snooping
  • Web-based GUI
Where to buy

Specification

Interfaces
8 x GE
Switching Capacity
16 Gbps
Max. Packet Forwarding Rate
11.9 Mpps
Max Power Consumption
4.94 W
Dimensions
171 x 98 x 29 mm
Weight
0.34 kg
FAN
Fanless
Operating Temperature
0°C - 40°C (32°F - 104°F)
Storage Temperature
-40°C to 70°C ( -40°F to 158°F)
Operating Humidity
0% to 90% RH, non-condensing
Storage Humidity
0% to 95% RH, non-condensing
Power Supply Type
External

Actual performances may vary due to settings, cabling, temperature, network configuration, interface, device compatibility, environmental and on-site conditions, and other similar factors. References to power capability, signal or processing speed, signal range or distance, data encryption, storage capacity, display properties, or other performance metrics are based on optimal conditions derived from industry standards and provided for informational purposes only. Specifications may be subject to change without prior notice.
