26-Port Gigabit PoE Easy Smart Switch

DGS-1100-26MPV2

  • Product Status (Ax v2.11WW): Live
  • 24 Ports GE PoE Ethernet for downlink
  • 2 Ports 1G Combo for uplink
  • PoE IEEE 802.3af/at options, power budget 370W
  • 2 smart fan
  • Broadcast/Multicast/Unicast Storm Control
  • 802.3ad / 802.1AX Link Aggregation
  • 802.1D STP/ 802.1w RSTP
  • IGMP Snooping
  • Nuclias Unity
  • SSL support
Where to buy

Specification

Interfaces
24 x 1GE PoE
2 x 1G Combo
Switching Capacity
52 Gbps
Max. Packet Forwarding Rate
38.69 Mpps
PoE Standards
IEEE 802.3af/at
PoE Power Budget
370W
Max Power Consumption
454.1 W (PoE on)
26.5 W (PoE off)
Dimensions
440 x 208 x 44 mm
Weight
2.8 kg
FAN
2 x Smart fans
Operating Temperature
-5°C to 50°C (23°F to 122°F)
Storage Temperature
-40°C to 70°C ( -40°F to 158°F)
Operating Humidity
0% to 95% non-condensing
Storage Humidity
0% to 95% non-condensing
Power Supply Type
Internal

Actual performances may vary due to settings, cabling, temperature, network configuration, interface, device compatibility, environmental and on-site conditions, and other similar factors. References to power capability, signal or processing speed, signal range or distance, data encryption, storage capacity, display properties, or other performance metrics are based on optimal conditions derived from industry standards and provided for informational purposes only. Specifications may be subject to change without prior notice.
